Differential pressure governor

D.1.08. - range -0,7+30bar fixed difference

Download

• Datasheet

Description

• case: plastic
• inspection hole: acrylate
• connection: threaded or hose
• design: 2x bottom, 1x bottom /1x upper

Application

• heating industry
• hydraulics
• air-conditioning
• power engineering

Technical parameters

• measuring ranges (switching difference): -0,7+6bar (0,6+4)bar, -0,7+6bar (0,6+4)bar, 0,7+6bar (doubled voltage=1), 8+30bar (fixní3+5)bar), 8+30bar (doubled voltage=4)bar
• working pressure: (factory setting) / max. pressure - (3/2) / 16,5bar, (2/15) / 35bar, (3/2) / 16,5bar, (20/manual reset) / 35bar, (3/manual reset) / 16,5bar
• connection thread: 2x G1/4 or hose
• throw-over contacts: 250V/12A

Specification

Pressure governors are designed to maintain a desired static pressure range according to switching value and difference settings.

They can be used for all gas and liquid mediums, which do not have a corrosive effect on copper alloys. Permissible medium temperature 10°C +120°C or -45°C +110°C depending on design.

Pressure governors are supplied with 2x G1/4 connection or hose connection. They are designed for fixed pipeline installation or wall bracket mounting, which is part of the packing.
